87
13
PROPELLER TABLE
ENOM01108-1
To ensure optimum performance, the propeller should match the boat type and its
load.
Use a genuine propeller.
When selecting propeller, make sure that RPM stays in the maximum operating range of
engine at wide open throttle.
40D2: 5000 - 5700 min
-1
(rpm)
50D2: 5150 - 5850 min
-1
(rpm)
Mark
Propeller Size (Diameter Pitch)
Inch mm
Heavier Load
Lighter Load
7* 11.4 x 7.1 290 x 180
9 12.1 x 9.0 311 x 229
11 11.6 x 11.0 290 x 279
12 11.4 x 12.0 283 x 305
13 11.1 x 13.0 277 x 330
14 11.1 x 14.0 279 x 356
15 11.0 x 15.0 279 x 381
* shows propeller with four blades.
