TOHATSU MFS 60A User Manual

5
5-3
4st 60 2019
Magneto P/L Fig. 7
å
∫
4
5
1
6
2
15
14
17
19
6
15
16
22
22
23
21
20
3
7
24
13
8
12
8
9
26
10
11
25
8
9
26
13
18
19
23
150 N·m (110 lb·ft) [15.0 kgf·m]
SOC
OIL-COMP.
SOCSOC
G17G17
BOND
G17
G17G17
BOND
G17
OI
L-C
OMP.
GM
SOCSOC
SOC
Ref.
No.
Description
Q'ty
Remarks
1 Flywheel W/Gear 1
2 Alternator Ass'y 1
3 Key 19-7-5 1
4 Nut 20-p1.25 1 M20
5 Washer 20.5-37-5 1 M20
6 Bolt 3 M6 L=25mm
7 Ring Gear Cover 1
8 Grommet 16-2.5 3
9Hook 2
10 Bolt 1 M6 L=20mm
11 Washer 6-16-1.5 1 M6
12 Collar 6.2-9-7.4 1
13 Grommet 13-2 2
14 Coil Bracket 1
Ref.
No.
Description
Q'ty
Remarks
15 Bolt 6 M6 L=25mm
16 Dowel Pin 6-12 2 Cylinder Blok-Coil Braket
17 Pulsar Coil 1
18 Pulsar Coil Guard 1
19 Screw 2
20 Ignition Coil W/R-cap 3
21 Plug Cap W/Resistance 3
22 Bolt 6 M6 L=20mm
23 Stay 3
24-1 Caution Decal (B) 1
24-2 Caution Decal (B) 1
25 Fuse Decal 1
26 Bolt 2 M8 L=30mm
