TOHATSU MFS 60A User Manual

5
5-15
4st 60 2019
3
1
4
21
22
20
15
17
16
18
Fig.3-52
18
9
10
13
11
13
2
6
14
19
Fig.10-1
12
6
4
3
3
3
Fig.15-30
短 長 短
Short
Long
Short
5
5
8
8
7
1
12 N·m (9 lb·ft) [1.2 kgf·m]
2
24 N·m (18 lb·ft) [2.4 kgf·m]
30 N·m (22 lb·ft) [3.0 kgf·m]
1
6 N·m (4.5 lb·ft) [0.6 kgf·m]
2
11.5 N·m (8.5 lb·ft) [1.15 kgf·m]
TB
13 4 2
134 2
LT
518
518
4st OIL
4st
OIL
18 N·m (13 lb·ft) [1.8 kgf·m]
3/4 rotating (270˚)
after finger tighten
Cylinder • Crankcase P/L Fig. 1
518518
LT
518
TB
1342
1342
4st
OIL
4st OIL
Ref.
No.
Description
Q'ty
Remarks
1 Cylinder Block & Crankcase Ass'y 1
2 Oil Filter Bolt 1
3 Dowel Pin 6-12 4 Crankcase-Cylinder Block
4 Bolt 8-90 8
5Washer 8M8
6 Bolt M6-35 10 M6 L=35mm
7 Water Jacket Insert (R) L=55 1 Long
8 Water Jacket Insert (L) L=35 2 Shot
9Anode 1
10 Bolt 1 M6 L=35mm
11 Exhaust Cover Ass'y 1
Ref.
No.
Description
Q'ty
Remarks
12 Exhaust Cover Gasket 1
Do not reuse.
13 Bolt 8 M6 L=25mm
14 Oil Filter 1
15 Thermostat 1 Mark 60
16 Thermostat Cap 1
17 Thermostat Cap Gasket 1
Do not reuse.
18 Bolt 4 M6 L=35mm
19 Engine Basement Gasket 1
Do not reuse.
20 Hanger 1
21 Bolt 1 M8 L=35mm
22 Washer 1 M8
