TOHATSU MFS 60A User Manual

5
5-11
4st 60 2019
Ref.
No.
Description Q'ty Remarks
1 Intake Manifold 1
2 Isc Valve 1 Idle Speed Control Valve
3 Bolt 2 M6 L=20mm
4 MAP Sensor 1 Manifold Air Temperature & Pressure
5 Bolt 1 M6 L=20mm
6 Fuel Rail Ass'y 1
7 Fuel Injector Ass'y 3
8 Bolt 2 M6 L=20mm
9 Throttle Body Ass'y 1 ø45
10 Gasket 1
Do not reuse.
11 Bolt 3 M6 L=20mm
12 Intake Silencer Ass'y 1
13 Gasket 1
Do not reuse.
14 Bolt 2 M6 L=25mm
15 Vapor Separator Ass'y 1
16 Float 1
17 Float Arm Pin 1
18 Float Valve Ass'y 1
19 Fuel Feed Pump 1 Upper
20 Grommet 1 Upper
21 Joint 1 Upper
22 Grommet 1 Upper
23 Filter (Outlet) 1 Lower
24 Grommet 1 Lower
25 Filter (Inlet) 1
26 Fuel Regulator 1
27 Holder 1
28 O-ring 1
Do not reuse.
29 O-ring 1
Do not reuse.
30 Drain Screw 1
31 Cover 1
32 Seal 1
Do not reuse.
