2-2
Service Data
4st 60 2019
1. Specifications
Item Unit
Model
MFS60A
ET
(with Remote Control)
ET
(with Multi Tiller Handle)
Overall Length mm (in) with Remote Control : 783 (30.8) with Multi Tiller Handle : 1,382 (54.4)
Overall Width mm (in) 404 (15.9)
Overall Height
S mm (in) 1,257 (49.5)
L mm (in) 1,390 (57.4)
UL mm (in) 1,504 (59.2)
Transom Length
S mm (in) 405 (15.9)
L mm (in) 538 (21.2)
UL mm (in) 652 (25.7)
L kg (lb) 97 (214) 102 (225)
UL kg (lb) 100 (221) 105 (231)
Maximum Output kW (ps) TAC 44kW (60PS) / EU 44.1kW (60PS)
Full-throttle revolution
speed range
r/min 5,000 to 6,000
Full-throttle Fuel
Consumption
L (gal.)/hr 17.8 (4.70)
Idling (Neutral [N]) r/min 650/750/850/950
Trolling (Forward [F]) r/min 650/750/850/950
Engine Type 4 stroke
No. of Cylinders 3
Piston Displacement cm³ (cui) 866 (52.8)
Valve System SOHC
Bore x Stroke mm (in) 70 x 75 (2.76 x 2.95)
Compression Ratio 10.5
Shift Operation
System
Remote
Control
Front Shift
(Manual)
Starting System Electric Start
Lubrication System Wet Sump
Cooling System Water Cooling (Impeller System)
Exhaust System Through-the-prop Exhaust
Ignition System Battery Ignition
Range of Ignition
Angle
ATDC5° to BTDC20° (ECU timing control)
Spark Plugs IKR6G8 [NGK]
Alternator Output 12V−252W, 21A
Fuel Feed System Electronic Fuel Injection
Dimensions (approx.)
Weight (approx.)
Performance
Power Unit
