4st 60 2019
Type of Fuel
Unleaded Gasoline (Research Octane Number 90 or over, Pump posted Octane Number 87 or over)
Fuel Tank Capacity L 25
Fuel Priming System
ECU (Electronic Control Unit)
Fuel Pumping System Mechanical (Plunger) pump + Electric System
Engine Oil
Type 4 Stroke Engine (Motor) Oil
Grade
API SH, SJ, SL
SAE 10W-30, 10W-40
Quantity L 2.4 (when oil filter is replaced with new one)
Gear Oil
Type Hypoid Gear Oil
Grade
*1 API GL-5
*1 SAE #80-90
Quantity cm³ (US qt) 500 (0.53)
Fuel & Oil
Gear Shift Positions F – N – R
Gear Ratio 2.08 (13 : 27)
Type of Gears
Spiral Bevel Gear
Clutch Dog Clutch
Propeller Shaft Driving
Spline
Propeller Rotation
Direction
Clockwise at forward (F) shift as viewed from rear
Propeller (Standard) Marking 14P
Lower Unit
No. of Trim Steps Steps 4
Trim Angle (Transom 12)
*2 Degrees −4° to +16°
Shallow Water Drive
Angle (Transom 12)
*2 Degrees Adjustable
Max. Tilt Angle *3 Degrees 62
Steering Angle *4 Degrees 35+35
Max. Allowable Transom
Thickness
mm (in) 31 to 70 (1.22 to 2.76)
Bracket
*1 Both API and SAE requirements shall be met.
*2 Angle relative to horizon when transom angle is 12 degrees.
*3 Tilting Range
*4 Full Steering Angle Range to Starboard and Port
Item Unit
Model
MFS60A
ET
(with Remote Control)
ET
(with Multi Tiller Handle)
