 DIGITAL TORQUE WRENCH “DATA TORK” MODEL CEM3-G
(7) Output data at a time (Infrared output)
Transfer the selected range of measured data to R-DT999 Data Tank.
Set the communication setting to "IFR" (Refer to P23 (8) Communication setting).
DUAL MODE LCD MODE
N·m
52.0
10 : 30
200
N·m
200
52.0
Set the upper end (Counter 200)
N·m
1
200
STT
N·m
001
STT 1
Set the lower end (Counter 1)
N·m
200
200
N
N·m
n
200
Number of data to output
N·m
200
N
N·m
200
52.0
Data transfer complcfe
N·m
200
200
N
N·m
n
200
1. Use key to set to the
upper end of the counter to
output and push .
The example shows the counter
200.
2. Use key to set to the
lower end of the counter to
output and push .
Note) In M-2 mode, lower end can
only be set to 1 (STT1).
Example 1) To output the data 001-200:
Set the counter to 200 and push . Check
STT shows 1 and push to confirm.
Example 2) To output the data 101-200:
Set the counter to 200 and push . Then
set STT to 101 and push MD to confirm.
3. Set R-DT999 ready for receiving
data, and place its input in line
with CEM3 output.
Push to output the
measured data to R-DT999.
Note) To cancel the operation, push
key. (You cannot cancel
when the data is being
output.)
Push MEM key to start output
