 DIGITAL TORQUE WRENCH “DATA TORK” MODEL CEM3-G
15
Specifications
Approx 46
Approx 57
100
I2
Effective length L
Overall length L'
I1
h1
P
CEM100N3
X15D-G
Capacity
Max
Newton Metric American Hand
Min. Max. 1digit Min. Max. 1digit Min. Max. 1digit
Power
[N·m] [N·m] [kgf·cm] [kgf·cm] [lbf·in] [lbf·in] P [N]
CEM10N3X8D-G 2-10 0.01 20-100 0.1 20-90 0.1 48.1
CEM20N3X10D-G 4-20 0.02 40-200 0.2 36-180 0.2 92.2
CEM50N3X12D-G 10-50 0.05 100-500 0.5 100-450 0.5 196.9
CEM100N3X15D-G 20-100 0.1 200-1000 1 200-900 1 275.5
[lbf·ft] [lbf·ft]
CEM200N3X19D-G 40-200 0.2 400-2000 2
30-150 0.2
428.3
CEM360N3X22D-G 72-360 0.4 720-3600 4 52-260 0.4 498.6
[kgf·m] [kgf·m]
CEM500N3X22D-G 100-500 0.5
10-50 0.05
72-360 0.5 549.5
CEM850N3X32D-G 170-850 1 17-87 0.1 124-620 1 608
Torque Range
Dimension
Effective Overall
Handle Handle
Height
Weight
Accessory
Interchangeable Heads
Length Width Provided
L [mm] L' [mm] l1 [mm] l2 [mm] h1 [mm] [kg]
CEM10N3X8D-G 208 212 63.5 35.6 49.5 0.46 QH8D (SH,RH,QH,HH) 8D
CEM20N3X10D-G 217 214 63.5 35.6 49.5 0.47 QH10D (SH,RH,QH,DH,HH) 10D
CEM50N3X12D-G 254 282 130 36.4 59 0.58 QH12D
Battery
(SH,RH,QH,RQH,DH,HH) 12D
CEM100N3X15D-G 363 384 130 36.4 59 0.63 QH15D
pack
(SH,RH,QH,RQH,DH,HH) 15D
CEM200N3X19D-G 467 475 130 36.4 59 0.78 QH19D
(BP-5)
(SH,RH,QH,RQH,DH,HH) 19D
CEM360N3X22D-G 722 713 130 36.4 59 1.13
QH22D
CHARGER
(SH,RH,QH,RQH,DH,HH) 22D
CEM500N3X22D-G 910 949 230 30 46 4
CEM850N3X32D-G 1398 1387 230 30 46 5.14 QH32D (SH,RH,QH) 32D
Dimensions
