Tohnichi DATA TORK CEM3-G User Manual

14
 DIGITAL TORQUE WRENCH “DATA TORK” MODEL CEM3-G
(2) Inspection mode with OK/NG judgement
It judges whether the measured data is within the set range.
(OK: Upper limit  Measured torque  Lower limit)
Setting (example)
Measurement mode: MODE-M
Upper limit: 55 Nm
Lower limit: 50 Nm
DUAL MODE LCD MODE
N·m
0.0
09 : 30
001
N·m
001
0.0
Set the counter to 001
N·m
50.0
09 : 30
001
N·m
001
50.0
Apply torque
1. Set the counter to 001-999 (M-3
mode) or 01-99 (M-2 mode).
2. Apply torque and push
to proceed to judgement.
Note) If you set Auto memory/reset,
judgement will be given
automatically after the set timing).
Note) When connected to PC or printer,
the measured data will be output.
In case of OK judgement
Green LED turns on for 0.5 sec
and proceeds to the next counter.
In case of NG judgement
Red LED turns on and the buzzer
sounds.
Note) In case of NG, Auto memory/
reset does not work.
To save the NG data, press
.
To delete the NG data, press .
N·m
50.0
09 : 30
001
N·m
001
50.0
(In case of OK judgement)
Push MEM for judgement
N·m
0.0
09 : 30
002
N·m
002
0.0
proceeds to next counter
Green
LED
N·m
0.0
09 : 30
001
N·m
001
0.0
(In case of NG judgement)
Set the counter to 001
N·m
60.0
09 : 30
001
N·m
001
60.0
Apply torque
N·m
60.0
09 : 30
001
N·m
001
60.0
Push MEM for judgement
Red
LED
CEM3-G取扱説明書.indd15CEM3-G取扱説明書.indd15 2016/07/1411:25:012016/07/1411:25:01
