DIGITAL TORQUE WRENCH “DATA TORK” MODEL CEM3-G
: Usable
: Not usable
: Usable in M-2 mode
(1) Battery pack (BP-5)
(2) Charger (100-240V) (BC-3-G)
(3) Interchangeable head (SH, RH, QH, RQH, DH, HH, FH)
PH of interchangeable head can not be used.
(4) Communication cord
• CEM3-PC (D-SUB 9 pin female) (Catalogue No.575)
• CEM3-PC (USB A type) (Catalogue No.584)
(5) Exclusive printer
(6) Infrared DATA TANK (R-DT999)
(7) Handy DATA FILE SYSTEM (DFS)
(8) Handy Terminal (HT-10)
• Comparison Table with CEM option
Options
Name Model CEM3-G CEM2
Battery pack BP-5
Battery pack BP-3
Charger (100-240V) BC-3-G
Charger (100V) QC-1
Charger (200V) QC-2
Interchangeable Head SH,RH,QH,RQH,DH,HH,FH
Exclusive printer
No.572
No.573
PC connection cord
No.574
No.575
PC connection cord (USB) Nl.584
Infrared data receiver R-DT999
Infrared data receiver R-DT100-3
Handy data file system DFS
Handy terminal HT-10
Handy terminal HT-9000
display
delivery
condition
select
1 Measurement Mode SEL MODE-M MODE-T
2 Torque Unit USEL N·m kgf·cm/kgf·m/lbf·in/lbf·ft
3 Upper limit HI 0 0
4 Lower limit Lo 0 0
5 Tightening direction tUrn CW CCW
6 Auto memory reset Ar 0.0 0.1-5.0
7 Buzzer output bU ON OFF
8 Communication mode do HT PC/PRN/USB/IFR
9 Baud rate bPS 2400 4800/9600/19200
10 Memory mode dCn M-3 M-2
11 Display mode dSP LED LCD
12 Setting default dFLt DFT-N DFT-Y
13 H:M:S rtC1 NON -
14 Y:M:D rtC2 NON -
CEM3-G
(EPP16M3)
EPP16M3
