①Setting the unit
②Setting the measurement mode
③Setting the upper limit
④Setting the lower limit
⑤Setting the tightening direction
５．Setting Mode
4
Press the key to turn on the power.
With a counter value of “0000” being displayed, hold down the key
for 2 seconds or longer to display the setting screen.To increment the
counter value, press the key together with the key.
The counter value is incremented in steps of 10; set to “0000”.
Further, by holding down the key, the counter value will decrement in
steps of 10 and will then stop at “0000”
Use the key to select a unit. Press the key to proceed to the
next step.
Press the key to return to the measurement screen.
Use the key to select a measurement mode.
Press the key to proceed to the next step. Press the key to
return to the measurement screen.
1 => 2 => 1 (Mode 1: Inspection mode, Mode 2: Tightening mode)
If the mode is changed over, the data measured in the previous mode is
cleared. If all right, press the key to proceed to the next step.
To output the data, press the key to return to the measurement screen.
Then, output the data.
Use the key to select a value. Press the key to shift a digit, and press
the key to proceed to the next step.
If the upper-limit value has been changed, the data measured using the
previous upper-limit value will be cleared. If all right, press the key
to proceed to the next step. To output the data, press the key to return
to the measurement screen. Then, output the data.
Use the key to select a value. Press the key to shift a digit, and
press the key to proceed to the next step.
If the upper-limit and lower-limit values have been zeroed, proceed to
⑥Setting the auto memory/reset.
If the lower-limit value has been changed, the data measured using the
previous lower-limit value will be cleared. If all right, press the key
to proceed to the next step. To output the data, press the key to return
to the measurement screen. Then, output the data.
Use the key to select the tightening direction. Press the key to
proceed to the next step. Press the key to return to the measurement screen.
CW => CCW => CW (CW: Clockwise, CCW: Counterclockwise)
To Next Page
