TOKNAV T20Pro - File Name Naming Rules; Rover Configuration (CH01)

TokNav Information Technology CO., LTD.
24
File name naming rules:
1.The time in file name is converted from
GPS time directly.
Assume GPS leap second is 18, Time Zone offset is
+08:00, Then 00:00:18 means 08:00:00 of local lime.
2.Key words in file name
yyyy
=> year
DOY
=> day of year, 000~366
MM
=> month, 01~12
X
=> hour, a~x, 0 when one file per day
dd
=> day, 01~31
SN
=> Serial Number
hh
=> hour, 00~23
SITE
=> Marker Name
mm
=> minute, 00~59
SSSS
=> Marker Number
ss
=> second, 00~59
When the device is set as rover station, base station or static mode, the device
will automatically configure the corresponding channel for data storage by default.
1. Rover (CH01)
When the device is set as a rover station, the device will automatically configure
CH01 to store and locate the original data by default. If PPK is enabled, CH05 will
also be automatically configured by default to store post positioning data, as shown in
the following figure.
