Tomey CASIA2 User Manual

■ 2-8
2.6.3 Measurement screen
(1) Eye selection button
The head moves to the corresponding side when the button is tapped.
(2) Patient information field
(3) Examination protocol name field
(4) Scan type field
Select a scan type for image capture. The selected scan type turns green.
(5) Number of times measurement data is saved
(6) Anterior eye section image field
When the image is tapped, the head moves so that the tapped point comes
to the center. The head moves forward when the center of the image is held
briefly.
(7) OCT live image field
The head moves along a line drawn on the image.
(8) Measurement settings
(9) Head retract button
The head retracts while this button is pressed down.
(10) “Exam Protocol” button
Displays the examination protocol screen and allows you to select an
examination protocol.
1
2
11
10
9 12
4
3
5
6
7
7
8
1
13
