Figure 4- test port
With the adoption of standard banana slots, the
instrument can use inexpensive banana plug-
crocodile clip as the test lead, which make the test
quite convenient. However this configuration has low
testing accuracy.
For the improvement of accuracy when using external
testing leads, TH2822 series are designed with 5-
terminal testing slots and exclusive test fixture to
ensure complete external 4-terminal test and
measuring accuracy.
