41
Default Equivalent Mode
When select primary parameter, equivalent mode
varies with primary parameter:
For capacitors and resistors, default equivalent
mode is PAL; for inductors, is SER.
Utility Menu (UTIL)
The LCR meter has a built-in utility menu that allows
you to configure some user preferences and settings.
The buttons used to set and control the menu are
colored in blue. There are three buttons: UTIL， ，
. User can configure the beep tone, auto power-off
timing, store/restore power-on state, view the battery
voltage, etc.
Entering Utility Menu
Long press UTIL button will enter utility menu. Primary
display is menu option and secondary display is the
current settings or parameters configured for the
selected option. After the entrance into utility menu,
the default menu option display will show “bEEP”.
