Tonghui TH2822 - Special Display Indicators; Test Port

19
29. TOL –Tolerance mode indicator
Special Display Indicators
Indicates short clear if you press the
CLEAR button
Indicates open clear if you press the
CLEAR button
Error indication
Indicates correction (open/short clear)
mode
Indicates damaged or open fuse
AD converter error（UNK）
AD converter error（END）
Test Port
TH2822 series are creatively designed to combine 3-
terminal port and 5-terminal port, which makes the
