59
• Do not leave the instrument exposed to explosive,
direct sun-lighting and overheating environments.
• Before removing the cover, ensure that none DUT
is connected to the meter and the instrument is
disconnected from any circuit and is powered OFF.
NOTE: To achieve optimum precision, please refer to
“Clear Function” for details before testing.
Inductance Measurement
1. Press the POWER button for a long time to turn
on the instrument.
2. Press the L/C/R/Z button until “L” is displayed on
the screen to select inductance measurement
3. Insert an inductor into test slots or connect a
tested inductor through a proper test accessory
(e.g., banana plug-crocodile clip test leads, test
fixture or SMD test tweezers). See figures 12. And
figure 13 shows the optional 4-terminal test
accessories.
4. Press the FREQ button until the desired test
frequency is displayed on screen.
