62
Capacitance Measurement
WARNING: Before testing, ensure that the
tested capacitor has been fully discharged.
1. Press the POWER button for a long time to turn
on the meter.
2. Press the L/C/R/Z button until “C” is displayed on
the screen to select capacitance measurement.
3. Insert a capacitor into test slots or connect a
tested capacitor through a proper test accessory
(e.g., banana plug-crocodile clip test leads, test
fixture or SMD test tweezers). See figure 14. And
figure 13 shows the optional 4-terminal test
accessories.
4. CAUTION: Before inserting a capacitor or
capacitive component into the input slots or
terminals, be sure to fully discharge the
component. Some larger capacitive
components may take longer to discharge. In
these cases, please allot enough time for a full
discharge. If improper discharging of the
component is done, it will damage the input
terminals of the meter.
5. Press the FREQ button until the desired test
frequency is displayed on screen.
