38
property of component according to the test result. It
is quite convenient for the measurements of mixed
and unknown components.
Enable Auto LCR Mode
Long press of AUTO button will activate auto LCR
mode. The “AUTO” indicator on LCD indicates that
auto LCR mode is activated.
In auto LCR mode, the match of secondary parameter
with primary parameter is shown as below:
Table1-Matching relations between primary and
secondary parameters in auto LCR mode
Primary Parameter
Phase Angle (θ)
In auto LCR mode, series or parallel equivalent mode
is selected in accordance with the magnitude of
impedance. Parallel mode is selected at high
impedance and series mode at low impedance.
