30
USING THE INSTRUMENT
ABBE COMPENSATION FUNCTION
WHEN THE ABBE NUMBER OF LENS IS KNOWN:(AT SEVERAL DESTINATION : d-LINE SETTING)
In the menu screen ABBE, select any of the following according to the Abbe number of
target lens:
Normal(50-60)
MID (40-50)
LOW (30-40)
LENS PROTECTION PAD
The attached lens protection pad allows a soft contact with the measuring lens.
1 Fit the lens protection pad according to the instructions.
2 Select , and the measurement result will be automatically
compensated.
COMPARTMENT SPACE
A space for keeping the contact lens holder, printer paper, etc. is secured in the back.
MENU/LENS/NORMAL(PAD)
