34
Surveying
• Setting attribute (only foresight)
2 Set the point number.
3 Press to confirm the point
number.
1 Press when measuring the
foresight point.
The attribute can now be set.
2 Set the attribute.
Each time or is pressed: IS
(intermediate sight) Æ FIX (fixed
point) Æ Off Æ FS (foresight) Æ IS
(intermediate sight)
Advancing the point number
If the point number is not set, data is recorded using the
automatically set number in the currently selected JOB. Check the
measurement results together with the point number. Point
number is displayed as follows:
• First record after power is switched ON • No data stored in JOB...
0001
• First record after power is switched ON • Data stored in JOB...
point number of last measurement point
• Second or later record after power is switched ON • turning
point...point number of last measurement point
• Second or later record after power is switched ON • No turning
point...point number of last measurement point +1
Notes:
