Topcon GPT-3002W Series - Page 108

8-10
8 LAYOUT
● Point Guide Function
The point guide function can be used while executing a Layout.
7
When the display value dHR, dHD and dZ are
equal to 0, the layout point is established.*3 )
8
Press the [F2](NEZ) key.
The coordinate data is shown.
[F2]
9
Press the [F4](NEXT) key to set next layout point .
PT# is automatically incremented.
[F4]
*1) Refer to Section 2.6 “How to Enter Alphanumeric characters”.
*2) Point number could not be entered when data to comply with the coordinate value does not exist in the
file.
*3) Cut & Fill displaying function is available . Refer to Chapter 16 “SELECTING MODE”.
Operating procedure Operation Display
10
Press the [F4](NEXT) key to set next layout point .
PT# is automatically incremented.
[F4]
1
After measuring Angle, Distance or Coordinate,
press the [MENU] key.
[MENU]
2
Press the [F3](ON) or [MENU] key.
[F3]
or
[MENU]
3
Press the [ESC] key to return to the previous
display.
[ESC]
N * 100.000 m
E : 100.000 m
Z : 1.015 m
MODE ANGLE NP/P NEXT
LAYOUT
PT#: LP-101
INPUT LIST NEZ ENTER
PT#:P1003
HR: 6°20'40"
dHR: 23°40'20"
DIST --- NEZ ---
LAYOUT
PT#: LP-101
INPUT LIST NEZ ENTER
POINTGUIDE [OFF]
––– ––– [ON][OFF]
POINTGUIDE [ON]
––– ––– [ON][OFF]
PT#:P1003
HR: 6°20'40"
dHR: 23°40'20"
DIST --- NEZ ---
