Topcon GPT-3002W Series - How to Set Selecting Mode

16-3
16 SELECTING MODE
*LANGUAGE selection is different in different countries.
16.2 How to Set Selecting Mode
<Example> : Setting unit in hPa, °F, NEZ MEMORY:ON
ACK MODE STANDARD /
OMITTED
Set the procedure of the communication with
external device.
STANDARD:Normal procedure
OMITTED:Even though the [ACK] is omitted
from the external device, the data is
not sent again.
GRID
FACTOR
USE G.F. /
DON’T USE
Select using GRID FACTOR in calculation of
measurement data.
CUT & FILL STANDARD /
CUT&FILL
In the layout mode, CUT & FILL can be
displayed instead of dZ.
ECHO BACK ON / OFF It is possible to output the data of echo back
type.
CONTRAST
MENU
ON / OFF When the instrument is turned ON, it is possible
to display the screen which you can adjust
contrast of the display and confirm the prism
constant (PSM), non-prism constant (NPM) and
atmospheric correction value (PPM).
Operating procedure Operation Display
1
While pressing [F2] key, turn power ON.
[F2]
+
Power ON
2
Press [F1](UNIT SET ) key.
[F1]
3
Press [F1](TEMP. & PRES.) key.
[F1]
4
Press [F2](°F) key, and press
[F4](ENTER) key.
[F2]
[F4]
5
Press [F1](hPa) key, and press [F4] (ENTER) key.
Returns to unit set menu.
[F1]
[F4]
6
Press [ESC] key.
Returns to PARAMETERS 2 menu.
[ESC]
PARAMETERS 2
F1:UNIT SET
F2:MODE SET
F3:OTHERS SET
UNIT SET 1/2
F1:TEMP. & PRES.
F2:ANGLE
F3:DISTANCE P
↓
TEMP. & PRES. UNIT
TEMP. = °C
PRES. = mmHg
°C °F ––– ENTER
TEMP. & PRES. UNIT
TEMP. = °F
PRES. = mmHg
hPa mmHg inHg ENTER
UNIT SET 1/2
F1:TEMP. & PRES.
F2:ANGLE
F3:DISTANCE
PARAMETERS 2
F1:UNIT SET
F2:MODE SET
F3:OTHERS SET
