Topcon GPT-7003i User Manual

106
15 MESSAGE/ERROR DISPLAYS
15 MESSAGE/ERROR DISPLAYS
15.1 Message
● If error still persist after attempting to clear them, contact your local Topcon dealer or Topcon head
office.
15.2 Error
● If error still persist after attempting to clear them, contact your local Topcon dealer or Topcon head
office.
Message code Description Countermeasures
[Please Input Value!]
No value was entered at time of
numerical value input.
Input numerical value.
[Please Input Exact Value!]
A value outside permissible range was
input at time of numerical value input.
Input exact numerical value.
[V Angle 0Set Error(Step1)]
V angle 0-set is over.
(in normal telescope)
Confirm the operation procedure is
correct and adjust again.
[V Angle 0Set Error(Step2)]
V angle 0-set is over.
(in reverse telescope)
[V Angle 0Set Over(Total)]
V angle 0-set is over.
(in normal and reverse telescope)
[V Angle Range Over] V angle range is over.
Adjust again from the beginning.
[V Angle Offset Range Over] V angle offset range is over.
[V Angle Tilt Offset Range Over] V angle tilt offset range is over.
Level the instrument properly and
adjust again.
[Collimation constant Range Over] Collimation constant range is over.
[Horizontal angle axis constant Range Over]
Horizontal angle axis constant range is
over.
[The range for adjusting the cross-hairs has
been exceeded.]
You have gone beyond the range in
which the cross-hairs can be adjusted.
Check the procedure, then carry out
adjustment again.
Error code Description Countermeasures
[Data Read Error 01~19] The data could not be loaded.
Close the program and restart the in-
strument.
If this error code continues to display,
repair is required.
[Data Set Error 01~10] The data could not be set.
[EDM Offset Read Error] The EDM offset could not be loaded.
[EDM Offset Set Error] The EDM offset could not be set.
[Ext Communication Retry Error]
The external communication could
not be accomplished.
Confirm the operation procedure is cor-
rect.
Confirm the cable connection is cor-
rect.
[XTILT OVER]
X tilt is over.
Instrument tilts over more than 4
minutes.
Level the instrument properly.
[YTILT OVER]
Y tilt is over.
Instrument tilts over more than 4
minutes.
[V-Angle Error]
Displayed when the telescope rotat-
ed too fast.
There is no error.
If this error code continues to display,
repair is required.
[H-Angle Error]
Displayed when the instrument rotat-
ed too fast
[Tilt Error]
Any abnormality occurs with Tilt sen-
sor.
Repair is required.
[E-60’] Any abnormality occurs with EDM.
[E-86]
[Internal Comm Error]
Any abnormality occurs with the in-
ternal communication of the instru-
ment.
Close the program and restart the in-
strument.
[E-99]
Any abnormality occurs with internal
memory.
Repair is required.
[E-5xx]
The image function could not be suc-
cessfully executed.
Close the program and restart the in-
strument. If an error is always dis-
played, repair is necessary.
