11
1 NOMENCLATURE AND FUNCTIONS
Telescope focusing knob
Telescope grip
Telescope eyepiece
Plate level
Circular level
Horizontal
motion clamp
Horizontal
tangent screw
Instrument
center mark
Battery cover
Adjusting screw
for circular level
Tribrach fixing lever
Power switch
Card cover
Card cover lever
*1) The position of vertical motion clamp and tangent screw will differ depend on the markets.
Vertical motion clamp
Vertical tangent screw *1)
2speed way:
GPT-7001i/7002i/7003i
1speed way:
GPT-7005i
USB port
Stylus pen
Battery cover lever
2speed way:
GPT-7001i/7002i/7003i
1speed way:
GPT-7005i
Operation keys
Display window
(With touch panel)
Hardware reset switch
(Inside the cover)
Cover sensor
(Inside the cover)
