28
1 NOMENCLATURE AND FUNCTIONS
Angle measuring mode
Distance measuring mode
Coordinate measuring mode
Page Display Function
1
0SET Angle of horizontal is set to 0° 00'00".
HOLD Holds the horizontal angle.
HSET Sets the horizontal angle by input value.
P1 The function of soft keys on next page (P2).
2
TILT
Sets the tilt function, ON/OFF.
If ON, the display shows tilt correction value.
V/% Switches the vertical angle and percent grade.
R/L Switches R/L rotation of horizontal angle.
P2 The function of soft keys on next page (P1).
1
MEAS Distance measuring starts.
MODE Sets to the mode for Tracking , Coarse or Fine.
--- ---
P1 The function of soft keys on next page (P2).
2
S.O To be stake out measurement mode.
--- ---
--- ---
P2 The function of soft keys on next page (P1).
1
MEAS Coordinate measuring starts.
MODE Sets to the mode for Tracking , Coarse or Fine.
--- ---
P1 The function of soft keys on next page (P2).
2
R.HT Sets a Reflector Height by input value.
INSHT Sets an Instrument Height by input value.
OCC Sets an occupied point by input values.
P2 The function of soft keys on next page (P1).
