9 CHECK AND ADJUSTMENT
9-16
8
Press the [F6](MEAS) key.
The measurement starts.
[F6]
The shifted quantity between H angle and V
angle measured from the measuring will be
calculated internally.
9
Press the [F5](YES) key.
The compensation value will be set and
memorized to GPT- 8 000A series.
The display will return to the main menu.
[F5]
● The display shows Compensation Range Overcoat when the calculated compensation value is
exceeded than limited value.
● If the distance between the instrument and the prism is not enough to adjust, the display shows The
distance is too short . The distance between the instrument and prism should be more than 35m.
● If the difference of the measured data between in normal position and in inverted position is exceeded
than limited value, the display shows Tolerance Limit Over .
● If the measuring is unstable when the atmospheric condition is bad or the optical path is interrupted,
the display shows Standard Deviation Over .
● To cancel the compensation, press the [F6](NO) key.
Adj Tracking Axis
Wait
Adj Tracking Axis
>Set OK?
YES NO
Complete
To Next Page
