3 AUTOMATIC TRACKING / AUTOMATIC COLLIMATION (GPT-8000A series)
3-1
3.1 Automatic Tracking
Measuring the moving target in automatic tracking mode.
• It is possible to perform auto-tracking only in prism mode. When switched to the automatic
tracking mode, it becomes prism mode from NP mode automatically. Moreover, after the end of an
automatic tracking does not return to Non-prism mode.
• The Coarse (10mm) mode is used for the moving target.
• Use a keyboard on the eyepiece side. When the keyboard on the opposition side is used an
error will be displayed to protect a worker from the radiation of the laser.
3 AUTOMATIC TRACKING / AUTOMATIC COLLIMATON
(GPT-8000A series)
WARNING
●
Cause eye injury or blindness.
Do not stare into beam.
CAUTION
●
Let the laser beam reach the aimed object or the target without anybody else in the laser beam path. In
case you operate laser beam open, avoid radiating laser beam to the height of man's head. It is quite
possible for the beam to enter into one's eyes, and it is possible to lose visual sight temporarily, and lose
one's caution and awareness of other dangers - avoid glaring beam.(GPT-8000A series)
WARNING
CAUTION
Operating procedure Option Display
1
Manually collimate the target prism using V/H
jog/shuttle.
2
Press the star [ ] key to show the star key
options.
[]
3
Press the [F1] key. The mode will be
automatic tracking mode.
The instrument searches the prism and tracks
automatically.
[F1]
V : 87°55'45"
HR: 180°44'12"
SD HD NEZ 0SET HOLD P1↓
2002-07-07 14:30:40
1
↓
NP/P
V : 87
°
55'45"
HR: 180
°
44'12"
SD HD NEZ 0SET HOLD
P1
↓
