Topcon GTS-235 User Manual

1-5
1 NOMENCLATURE AND FUNCTIONS
1.4 Function Key (Soft Key)
The Soft Key message is displayed at the bottom line of display. The functions are according to the
displayed message.
Angle measurement
Distance measurement mode
Angle measurement mode Distance measurement mode
Coordinates measurement mode
Page
Soft
key
Display
mark
Function
1
F1 0SET Angle of Horizontal is set to 0°00'00"
F2 HOLD Hold the horizontal angle
F3 HSET Sets a required horizontal angle by entering numerals.
F4
P1
↓
The function of soft keys is shown on next page (P2).
2
F1 TILT
Setting Tilt Correction
If ON, the display shows tilt correction value.
F2 REP Repetition angle measurement mode
F3 V% Vertical angle percent grade(%) mode
F4
P2
↓
The function of soft keys is shown on next page (P3).
3
F1 H-BZ Sets the buzzer sound for every horizontal angle 90°
F2 R/L Switches R/L rotation of horizontal angle.
F3 CMPS Switches the COMPASS ON/OFF of vertical angle.
F4
P3
↓
The function of soft keys is shown on next page (P1).
1
F1 MEAS Start measuring
F2 MODE Sets a measuring mode, Fine/Coarse/Tracking
F3 S/A Select set audio mode
F4
P1
↓
The function of soft keys is shown on next page (P2).
2
F1 OFSET Select Off-set measurement mode
F2 S.O Select stake out measurement mode
F3 m/f/i Switches meter, feet or feet and inch unit.
F4
P2
↓
The function of soft keys is shown on next page (P1).
H-BZ R/L CMPS P3
↓
TILT REP V% P2
↓
V: 90°10'20"
HR:120°30'40"
0SET HOLD HSET P1
↓
[F1] [F2] [F3] [F4]
Soft keys
OFSET S.O m/f/i P2
↓
HR:120°30'40"
HD*[r] <<m
VD: m
MEAS MODE S/A P1
↓
OFSET --- m/f/i P3
↓
R.HT INSHT OCC P2
↓
N: 123.456 m
E: 34.567 m
Z: 78.912 m
MEAS MODE S/A P1
↓
