1-6
1 NOMENCLATURE AND FUNCTIONS
Coordinate measurement mode
1.5 Star key mode
Press the (★) key to view the instrument options.
The following instrument options can be selected from the (★):
1. Adjustment the contrast of the display (0 to 9 steps) [or ]
2. Adjustment the reticle illumination (1 to 9 steps) [ or ]
3. Turn the backlight of the display ON/OFF [F1]
4. Setting Tilt Correction [F2]
5. Turn the Point Guide option ON/OFF [F3] (Only for point guide type)
6. S/A (set audio) mode [F4]
Note: Star key mode does not function when the same function as the function assigned to the star key
mode is performed from the main routine.
1
F1 MEAS Start measuring
F2 MODE Sets a measuring mode, Fine/Coarse/Tracking
F3 S/A Select set audio mode
F4
P1
↓
The function of soft keys is shown on next page (P2).
2
F1 R.HT Sets a prism height by input values.
F2 INSHT Sets an instrument height by input values.
F3 OCC Sets an instrument coordinate point by input values.
F4
P2
↓
The function of soft keys is shown on next page (P3).
3
F1 OFSET Select Off-set measurement mode
F3 m/f/i Switches meter, feet or feet and inch unit.
F4
P3
↓
The function of soft keys is shown on next page (P1).
key
Display
mark
Function
F1 B.LT Turn the backlight of the display ON/OFF
F2 TILT
Setting Tilt Correction
If ON, the display shows tilt correction value.
F3 P.G. Turn the Point Guide option ON/OFF (Only for point guide type)
F4 S/A
The light acceptance quantity level for the EDM (SIGNAL), the atmospheric
correction value (PPM) and correction value of prism constant (PSM) are
displayed.
or
CONT Adjust the contrast of the display (0 to 9 steps)
RTCL
Adjust the Reticle Illumination (1 to 9 steps)
ON/OFF of the reticle illumination is linked with ON/OFF of the back light.
or
V: 90°10'20"
HR:120°30'40"
0SET HOLD HSET P1
↓
CONT:5 ↕ RTCL:5 ↔
B.LT TILT P.G. S/A
Press the star (★) key.
