Topcon GTS-235 User Manual

6-16
6 SPECIAL MODE (Menu Mode)
6.2 Setting the GRID FACTOR
GRID FACTOR can reset in this menu mode.
For more information, refer to Section 8.1.1”Setting the GRID FACTOR”
Operating procedure Operation Display
1
After pressing the [MENU] key, press the [F4](P
↓
)
key to get the menu on page 2.
[MENU]
[F4]
2
Press the [F2](GRID FACTOR) key.
[F2]
3
Press the [F3](YES) key.
4
Press the [F1] (INPUT) key and enter Elevation.
*1) Press the [F4](ENT) key.
[F3]
[F1]
Enter ELEV.
[F4]
5
Enter Scale Factor in the same way.
[F1]
Enter Scale
[F4]
Grid Factor is displayed for 1 to 2 second and
display returns to menu.
*1) Refer to Section 2.6 “How to Enter Alphanumeric characters”.
● Input Range :Elevation : –9,999 to +9,999 meter (–32,805 to +3,2805 ft, ft+in)
Scale Factor: 0.990000 to 1.010000
MENU 2/3
F1:PROGRAMS
F2:GRID FACTOR
F3:ILLUMINATION P
↓
GRID FACTOR
=0.998843
>MODIFY? [YES][NO]
GRID FACTOR
ELEV.→1000 m
SCALE:0.999000
INPUT ––– ––– ENTER
1234 5678 90. –[ENT]
GRID FACTOR
ELEV.:2000 m
SCALE
→
1.001000
INPUT ––– ––– ENTER
GRID FACTOR
=1.000686
