4-11
4 DISTANCE MEASUREMENT
Collimate
P3
[F1]
The instrument calculates and displays coordinate
and distance value of cross point between
collimation axis and of the plane. *1),2)
6
Collimate the edge (P0) of the plane. *3) ,4)
Collimate
P0
7
To show the slope distance (SD), press th e []
key.
● Each time pressing the [ ] key, horizontal
distance, relative elevation and slope distance are
shown in sequence.
● To show coordinate of point P0, press the [ ]
key.
8
To escape the measuring, press the [F1](EXIT)
key. The display returns to the previous mode.
*1) In case the calculation of plane was not successful by the measured three points, error displays. Start
measuring over again from the first point.
*2) Data display is the mode beforehand of offset measurement mode.
*3) Error will be displayed when collimated to the direction which does not cross with the determined plane.
*4) The refrector height of the target point P0 is set to zero automatically.
PLANE
N003#:
SD: m
MEAS --- --- ---
HR: 80°30'40"
HD: 54.321 m
VD: 10.000 m
EXIT
HR: 75°30'40"
HD: 54.600 m
VD: -0.487 m
EXIT
V : 90°30'40"
HR: 75°30'40"
SD: 56.602 m
EXIT
