Topcon GTS-239W - Coordinate Data Direct Key Input

9-10
9 MEMORY MANAGER MODE
9.4 Coordinate Data Direct Key Input
Coordinate data for the layout point or control point can be input directly from the keyboard. This data
can be stored into a file in the internal memory.
Operating procedure Operation Display
1
Press the [F3](MEMORY MGR.) key from the
menu 1/3.
[F3]
2
Press the [F4](P
↓
) key.
[F4]
3
Press the [F1](COORD. INPUT) key.
[F1]
4
Press the [F1](INPUT) key and enter File Name
you want to input.
Press the [F4](ENT) key. *1)
[F1]
Enter FN
[F4]
5
Press the [F1](INPUT) key and enter PT#.
Press the [F4](ENT) key. *1)
[F1]
Enter PT#
[F4]
6
Enter coordinate data in the same way.
Next input display is shown, point number (PT#) is
automatically incremented.
[F1]
Enter COORD.
[F4]
*1) Refer to Section 2.6 “How to Enter Alphanumeric characters”.
MEMORY MGR. 1/3
F1:FILE STATUS
F2:SEARCH
F3:FILE MAINTAN P
↓
MEMORY MGR. 2/3
F1:COORD. INPUT
F2:DELETE COORD.
F3:PCODE INPUT P
↓
SELECT A FILE
FN:_________
INPUT LIST ––– ENTER
COORD. DATA INPUT
PT#:_________
INPUT LIST ––– ENTER
N
→
m
E: m
Z: m
INPUT ––– ––– ENTER
COORD. DATA INPUT
PT#:TOPCON-102
INPUT LIST ––– ENTER
