6.4.8 Confirming the Bluetooth™ Device Address and Setting the PIN code
You can confirm the Bluetooth™ address and set the PIN code
● Coincide PIN code of DK-7W with the one of total station.
If two PIN codes don’t coincide, the two instrument cannot communicate each other.
● To set the PIN code of the total station, refer to the instruction manual of the total station.
6.5 Setting Contrast of Display
Setting level for contrast of display (LCD)
Operating procedure Operation Display
1
After pressing the [MENU] key, press the [F4](P
↓
)
key twice to get the menu on page 3.
[MENU]
[F4]
[F4]
2
Press the [F1] key.
[F1]
3
Press the [F4] key.
[F4]
4
Press the [F4] key.
[F4]
5
Press the [F2] key.
The Bluetooth device address and PIN code will
display.
[F1]
6
To change the PIN code, press the [F1](INPUT)
key.
[F1]
7
Enter a new PIN code and press the [F4](ENTER]
key.
Enter PIN
code
[F4]
Operating procedure Operation Display
1
After pressing the [MENU] key, press the [F4](P
↓
)
key twice to get the menu on page 3.
[MENU]
[F4]
[F4]
2
Press the [F2] key.
[F2]
3
Press the [F1](
↓
) key or [F2](
↑
) key, and press the
[F4](ENTER) key.
[F1]or [F2]
[F4]
MENU 3/3
F1:PARAMETERS 1
F2:CONTRAST ADJ.
P
↓
PARAMETERS 1 1/3
F1:MINIMUM READING
F2:AUTO POWER OFF
F3:TILT P
↓
PARAMETERS 1 2/3
F1:ERROR CORRECTION
F2:BATTERY TYPE
F3:HEATER P
↓
PARAMETERS 1 3/3
F1:SELECT COM
F2:BLUETOOTH
P
↓
BLUETOOTH
ADDR. :000E14F49B4
PIN CODE : 1234
INPUT --- --- ENTER
BLUETOOTH
ADDR. :000E14F49B4
PIN CODE : 2233
1234 5678 90.- ENTER
MENU 3/3
F1:PARAMETERS 1
F2:CONTRAST ADJ.
P
↓
CONTRAST ADJUSTMENT
LEVEL: 4
↓ ↑
––– ENTER
