Topcon SL-1E - SPECIFICATIONS; MICROSCOPE; SLIT ILLUMINATION; BASE

20
SPECIFICATIONS
SPECIFICATIONS
MICROSCOPE
Type Binocular stereoscopic microscope with erect image.
Magnification changer
Revolver type objective changing system provides two magnifi-
cation changes.
Objective 1× and 1.6×
Eyepieces 10× and (16× option)
Magnification & field of view
Objectives × Eyepieces = Magnification Field of view
Pupillary adjustments 55mm to 75mm
Diopter adjustments -5D to +3D
SLIT ILLUMINATION
Slit projection 1.23×
Slit width Continuously variable from 0 to 14mm
Slit length 14mm, 10mm, 8mm, 5mm, 3mm, 2mm, 1mm
Aperture diameters 14mm, 10mm, 8mm, 5mm, 3mm, 2mm, 1mm
Slit angle Continuously rotatable from vertical to horizontal
Filters Blue, Red-free
Lamp 6V 20W halogen
BASE
Longitudinal movement 80mm
Lateral movement 100mm
Fine cross-slide adjustments 12mm
Vertical movement 30mm
CHINREST
Vertical movement 80mm
POWER
Source voltage
120V/220V AC (USA and Canada)
100/120/220/240V AC (except for USA and Canada)
Frequency 50-60Hz
Power input 30VA
DIMENSION & WEIGHTS
Dimensions
W/Table
W/Unit Table
W/O Table
W/O Table and Chinrest
550mm(W) × 398mm(D) × 552mm(H)
440mm(W) × 378mm(D) × 552mm(H)
329mm(W) × 276mm(D) × 405~435mm(H)
329mm(W) × 276mm(D) × 405~435mm(H)
1× 10× 10× 18mm diameter
1.6× 10× 16× 11.25mm diameter
1× 16× 16× 14.25mm diameter
1.6× 16× 25.6× 9mm diameter
