17
If the “11” is be set, the gate opener won’t work until the PBS system is equipped. The PBS
system works only when gate opener is closing. The gate opener will return to its open position when
the obstruction blocks the beam from photo eye.
even if the limit switch is invalid or the clutch is detached.
7-a. Adjust the MRT of MOTOR1
When the Digital Display indicates “P7”, you can adjust the MRT of MOTOR1.
The MRT of MOTOR1 is adjusted by pressing “INC” and “DEC” buttons respectively. The Digital Display will
show “01”-“50” which indicates the MRT of MOTOR1 from 1 to 50 seconds.
You can hold pressing the “INC” or “DEC” button for more than 1 second to speed up the setting. Press the
“FUNC” button to store the data when you finish setting. The Digital Display will indicate “P8”.
(Factory default setting is “40” seconds)
7-b. Adjust the MRT of MOTOR2
When the Digital Display indicates “P8”, you can adjust the MRT of MOTOR2.
Please perform the same procedure as adjusting MOTOR1 (7-a).
Press the “FUNC” button to store the data when you finish setting. The Digital Display will indicate “P9”. Now
MOTOR2 adjustment is finished.
8. Set the Safety Photocell Beam System (PBS) (Optional)
When the Digital Display indicates “P9”, the gate opener enters PBS set mode.
You can press and release the “INC” or “DEC” button to set or shut off the PBS function. The Digital Display
indicates “11”, the PBS is available. The Digital Display indicates “00”, the PBS is null.
Press the “FUNC” button to store the data when the PBS is set. The Digital Display will indicate “PA”.
(Factory set is “00”)
9. Set the Automatic Closing Time
When the Digital Display indicates “PA”, the gate opener enters into the setting of automatic closing time mode.
Press and release the “INC” or “DEC” button, the Digital Display will show a “01”-“99” which indicates the
current automatic closing time. The minimum time is 1 second, 99 seconds maximum. Each time you press and
release the “INC” button, the figure increases by 1, and the timing increases by 1 second. Each time you press
and release the “DEC” button, the figure decreases by 1, and the timing decreases by 1 second. When the
timing is “00”, the automatic closing function is shut off and the gate will stay open.
(Factory set is 60 seconds)
Press the “FUNC” button to store the data when the desired automatic closing time is set. The Digital Display
will indicate “Pb”
10. Set the Period of Soft Start
When the Digital Display indicates “Pb”, the gate opener is ready for setting period of soft start.
You can press the “INC” or “DEC” button to set the period of soft start. There is 1-9 seconds available in setting.
Press the “FUNC” button to store the data when the period is set. The Digital Display will indicate “PC”.
(Factory set is 3 seconds)
11. Set the Fast Running Period (FRP) to Achieve Soft Stop Function (SPP)
When the Digital Display indicates “PC”, the Fast Running Period for opening or closing gate is adjustable by
pressing “INC” and “DEC” buttons respectively, and the Soft Stop Function is achieved simultaneously.
The Soft Stop means the gate opener runs at slow speed during the last period before the gate completely
closes. The Soft Stop Period is unavailable by direct adjust but available through adjusting the Fast Running
Period.
There are two running speeds designed in program, i.e. Fast Running Speed and Soft Running Speed. The
Fast Running Period is adjustable from 1 to 28 sec. Factory default setting is 15 sec.
Since the GATE OPENING OR CLOSING RUNING PERIOD (GRP) = SOFT START PERIOD (STP) + FAST
RUNNING PERIOD (FRP) + SOFT STOP PERIOD (SPP), the SPP could be extended by shortening the FRP
when the GRP and STP are fixed. In other words, SPP = GRP–STP–FRP.
