INSTALL THE BT30 ENCODER
8. Install the encoder read head on the head casting with the button head cap screws using a 3 mm hex
wrench. Leave the encoder just loose enough to make final adjustments later in this procedure.
Figure 16: Encoder read head installed on the head casting.
