4 Instructions for Use TORMAX 1102, 1201 T-1661 e
<
1.4 Explanation of the Symbols
Warning (signal word)
Source of hazard (designates a possibly hazardous situation)
Possible consequences of non-observance
• Measuresforavertingdanger.
Text which is highlighted in grey MUST be observed to ensure that the system operates perfectly.
Failure to observe these sections can cause damage to equipment.
Functions marked with this symbol are the factory setting. However, they can be reprogrammed
by a specialist.
Optional components which are not present in all systems.
1.5 Technical Data
Drive type Electromechanical swing door drive with DC motor
Control system Microprocessor 32 Bit
Mains connection 1 x 230 / 1 x 115 V AC, 50 – 60 Hz, 10 A
Power consumption 3 … 200 W
Sensor supply 24 V DC 1,5 A
Protective class, drive IP20
Ambient temperature –20 °C to +50 °C
Fuse 5 AT
Drive weight
TORMAX 1102 11,2 kg
TORMAX 1201 11,8 kg
Noise emission level < 70 db (A)
