12 Instructions for Use TORMAX 1102, 1201 T-1661 e
3.3 Operating Modes
The automatic door system can be operated with the TORMAX user interface u (5 operating modes
and status display) or with an operating mode switch u (3 operating modes).
Operating Mode OFF
The internal and external sensors are disregarded. The door is mechanically held in the closed position
and locked using an electric lock u. Access is only possible using the key switch or if the door is
manually unlocked using a key or the door handle is used to open the door manually.
The door can still be used for 5 seconds after selecting operating mode OFF. The door then locks at
the end of this period as soon as it is closed. The transition is signalled on the user interface by the
flashing display of operating mode OFF.
Operating Mode AUTOMATIC
The operating mode AUTOMATIC is normally used during the day. The door opens automatically through
the inside and outside sensors. The door can behave differently depending on the settings programmed
during commissioning:
“Push-and-Go”
If the door is manually pushed in the opening direction, it reacts as if to a command to open: it opens
automatically, waits for the hold-open time and then closes.
Systems with an Electric Door Lock u
The lock unlocks on every valid opening impulse. The door lock must be manually unlocked with the
doorhandlebeforeitispossibletoopenthedoorwiththe“Push-and-Go”system.Inthisoperating
mode the door lock can also be permanently unlocked depending on the setting programmed at the
time of commissioning.
Operating Mode EXIT
Operating mode EXIT is normally used for the period before the shop or office closes. The door will
only open automatically when activated by the internal sensor. When the door opens the external sen-
sor is also monitored for safety reasons. The open position is determined by the preceding selection
of the operating mode AUTOMATIC. Additionally the door can be locked automatically by the door
lock u. The door lock can be permanently unlocked in this operating mode in case of need.
Operating Mode OPEN
The door opens and remains open. The open position is determined by the preceding selection of the
operating mode AUTOMATIC. The door opens again on receiving the next open impulse or when
changing the operating mode to OFF and back again to OPEN.
Operating Mode Manual Operation
The door leaf can be freely moved. This operating mode can be used for cleaning the door leaf or for
temporarily shutting down the door. The system is reset after leaving this operating mode. On each
opening command In this operating mode the door lock is unlocked during 10 s.
After a single leaf of a double leaved door has been opened manually, the closing sequence is main-
tained mechanically by means of a mechanical door coordinator. If there is no mechanical door coor-
dinator, the door leaves can be opened manually independently of each other without regard to the
overlap on the door leaves.
