Tormax 1102 User Manual

Instructions for Use TORMAX 1102, 1201 T-1661 e 9
1 Drive
a) Motor and spring unit
b) MCU42 control system with monitoring system, power limitation and
permanent diagnosis.
£
Controlled closing function of the door in power-off condition
£ Controlled opening function in power-off condition
c) Linkage / sliding lever
2 Drive accessories u
a) £ Emergency power supply via the battery unit
b) £ Mechanical
door coordinator for double-leaf doors
c) £ Driver flap to the mechanical door coordinator
£ …
3 Door leaves
a) Swing leaf with main closing edge (HK) and secondary closing edge (NK)
b) £ Finger protection to enhance the safety of the secondary closing edge.
4 Operating controls
a) £ User interface with 5 operating modes and fault display
b) £ Operating mode switch with 3 positions.
c) £ Lock for the user interface
d) £ Remote control of operating modes
e) £ Switch for 1-leaf operation
5 Internal activators
a) With automatic activation b) With manual activation
£ Radar with/without direction recognition £ Push button
£ IR motion detector £ Contact-free button
£ Contact mat £
Button for passage with bed
£ … £ …
6 External activators
a) With automatic activation b) With manual activation
£ Radar with/without direction recognition £ Key switch
£ IR motion detector £ Card reader
£ Contact mat £ Remote control
£ … £
Button for passage with bed
£ … £ …
7 Safety sensors
a) £ Presence sensor safeguarding the swing area when closing
b) £ Presence sensor safeguarding the swing area when opening
£ …
8 Emergency systems
a) £ Power switch / fuse
b) £ Emergency-off switch
c) £ Fire alarm system
9 Output message
£ Bell / gong
£ Door status
10 Lock u
a) £ Electrical door opener
b) £ Door handle
c) £ Mechanical door lock
£ Depending on the system’s equipment
