g009705
Figure42
•Steeringcylinderballjoints(2)(Figure43)
g009706
Figure43
1.Topttingonkingpin
•Tierodballjoints(2)(Figure43)
•Kingpinbushings(2)(Figure43).Thetoptting
onthekingpinshouldonlybelubricated
annually(2pumps).
•Liftarmbushings(1percuttingunit)(Figure44)
g015159
Figure44
•Liftcylinderbushings(2percuttingunit)(Figure
44)
•Liftarmpivotbushings(1percuttingunit)(Figure
45)
40
