UsingtheMenus
ToaccesstheInfoCentermenusystem,pressthemenuaccess
buttonwhileatthemainscreen.Thiswillbringyoutothe
mainmenu.Refertothefollowingtablesforasynopsisof
theoptionsavailablefromthemenus:
MainMenu
MenuItemDescription
Faults
TheFaultsmenucontainsalistoftherecent
machinefaults.RefertotheServiceManual
oryourAuthorizedT oroDistributorformore
informationontheFaultsmenuandthe
informationcontainedthere.
ServiceTheServicemenucontainsinformationon
themachinesuchashoursofuseandbattery
usageandstatus.
DiagnosticsTheDiagnosticsmenulistsvariousstates
thatthemachinecurrentlyhas.Youcanuse
thistotroubleshootcertainissuesasitwill
quicklytellyouwhichmachinecontrolsare
onandwhichareoff.
AboutTheAboutmenuliststhemodelnumber,
serialnumber,andsoftwareversionofyour
machine.
SettingsTheSettingsmenuallowsyoutocustomize
theInfoCenterdisplay.
ServiceMenu
MenuItemDescription
Hours
Liststhetotalnumberofhoursthatthe
machinehasbeenturnedon.
MowTime
Liststhetotalnumberofhoursthatthereel
hasbeenturnedon.
PowerUseListstheinstantaneouspowerdeliveredby
thebatteryinWatts.
BatteryCharge
Liststhecurrentbatterychargeasapercent
ofcapacity.
BatteryCurrent
Liststheinstantaneouscurrentdeliveredby
thebatteryinAmps.
BatteryVoltsListsthebatterypotentialinVolts.
EnergyListsthetotalenergydeliveredbythebattery
overitsentirelifeinWatt-hours.
DiagnosticsMenu
MenuItemDescription
KeyOnIndicateswhethertheignitionkeyisonoroff.
KeyStart
Indicateswhethertheignitionkeyisinthe
Startpositionornot..
PBrakeLatchIndicateswhethertheparkingbrakelatchis
onoroff.
EZTurnIndicateswhethertheEZ-Turncircuitisopen
orclosed.
TractionIndicateswhetherthetractionleverisonor
off.
ReelEnableIndicateswhetherthereelisengagedornot.
ThrottleIndicatesthethrottlecontrolsettinginVolts
(usedtocalculatethetargetrpm).
TargetrpmListsthedesiredmotorrpmasindicatedby
thespeedcontrolsetting.
MotorrpmListstheactualmotorrpm.
12VSupplyListsthesensorsupplyvoltage#1ofthe
controller.
5VSupplyListsthesensorsupplyvoltage#2ofthe
controller.
CANBus
Liststhemachinecommunicationbusstatus.
AboutMenu
MenuItemDescription
Model
Liststhemodelnumberofthemachine.
SNListstheserialnumberofthemachine.
S/WRevListstherevisionnumberofthemachine
software.
