SettingsMenu
MenuItemDescription
LanguageUsethissettingtochangethelanguageused
ontheInfoCenter.
UnitsUsethissettingtochangetheunitsused
bytheInfoCenter.Themenuchoicesare
EnglishandMetric.
LCDBacklight
Usethissettingtoincreaseordecreasethe
brightnessoftheLCDdisplay.
LCDContrast
Usethissettingtochangethecontrast
betweenthedarkandlightareasoftheLCD
display.
Note:Ifyouinadvertentlychangethelanguageorcontrast
toasettingwhereyoucannolongerunderstandorview
thedisplay,contactyourAuthorizedToroDistributorfor
assistanceinresettingthedisplay.
ReleasingtheTransmission
Ifthemachinebecomesdisabledwiththemotorbrakeon,
youcandisengagethedrumfromthetransmissiontoallow
themachinetobemaneuvered.
1.Ontherightrearcornerofthemachine,locatethe
tractionengage/disengagelevernexttothedrive
housingdrum(Figure36).
1
2
G017247
Figure36
1.Traction
engage/disengage
lever-engaged
2.Traction
engage/disengage
lever-disengaged
2.Rotatetheleverrearwardtodisengagethetransmission
fromthedrum.
Important:Makesuretopushtheleverfromthe
fronttopreventyourhandfrombeingstruckby
thespringloadedlever.
3.Movethemachineasneeded
Important:Ifpossible,donottowthemachine.If
itisabsolutelynecessary,donottowatanyspeed
greaterthan4.8kph(3mph);alwaysdisengage
thetransmissionfromthedrum.Failingtodoso
willlikelycausedamagetothemachine,especially
theelectricalcomponents.
4.Whennished,rotatetheleverforwardtoengagethe
transmissiontothedrum.
Note:Theservicebrakeisstilloperationalwiththe
transmissiondisengagedfromthedrum.
29
