ChuteAssemblyRemoval(continued)
g352578
Figure119
13.Removethechutefromthedeck.
ChuteAssemblyInstallation
1.Installthechutetothedeck,securewith4(1/4–10inch)screws.Torquethe
screwsto3.39±0.45N•m(30±4in-lbs).
g352578
Figure120
2.Installthebeltguideguardontothedeck,securewith2(1/4–10inch)screws.
Torquethescrewsto3.39±0.45N•m(30±4in-lbs).
