AWDRearTransmissionInstallation(continued)
g359966
Figure142
3.Installthetransmissionintothechassiswiththebelt.
4.Routethebeltbetweentheidlerpulleyandinputpulley.
5.Installtherearheight-of-cutplates.RearHeight-of-CutInstallation(page
6–16)
6.Installthebeltguideguardontothedeck,securewith2(1/4–10inch)screws.
Torquethescrewsto2.82±0.56N•m(25±5in-lbs).
g352577
Figure143
7.Installthebafeontothedeck,securewitha(1/4–10inch)screw.T orquethe
screwto2.82±0.56N•m(25±5in-lbs).
22InchAWD/RWDSteelDeckWalkPowerMowerService
Manual
Page7–15
DriveSystem:ServiceandRepairs
3445-579RevA
