BatteryAssemblyRemoval(ElectricStartModelsOnly)(continued)
g352577
Figure172
9.Removethebeltguideguardfromthedeck.
10.Removethe2(M4.5x2.0)screwssecuringthebatterytraytothechassis.
Removethebatterytrayfromthechassis.
BatteryAssemblyInstallation(ElectricStartModelsOnly)
1.Installthebatterytraytothechassis,securewiththe2(M4.5x2.0)screws.
Torquethescrewsto2.26±0.34N•m(20±3in-lbs).
2.Installthebeltguideguardontothedeck,securewith2(1/4–10inch)screws.
Torquethescrewsto2.82±0.56N•m(25±5in-lbs).
g352577
Figure173
3.Installthebafetothedeck,securewitha(1/4–10inch)screw.T orquethe
screwsto2.82±0.56N•m(25±5in-lbs).
