Figure 3
1. Center Gage Wheels and
Spacer
4. Angle bracket-discard
2. Nut
5. Small washer
3. Large washer-discard
2. Install the center g ag e wheels with the
previously remo v ed bolt, spacer , small w asher ,
and n ut ( Figure 4 ).
Figure 4
1. Center Gage Wheels and
Spacer
4. Washer
2. Nut 5. Spacer
3. Bolt
3. R emo v e the hair pin cotter and w asher on both
front height-of-cut posts ( Figure 5 ). Discard
the w ashers , these are not to be used for
adjusting the height-of-cut.
Figure 5
1. Hairpin cotter
3. Height-of-cut post
2. Shipping washer
4. Mower
Step
2
Installing the Handle
Assembly
Parts needed for this step:
1
Handle assembly
4
Flanged bolt, 3/8 x 1 inch
4
Flange nut, 3/8 inch
Procedure
1. Align handle with upper mounting holes in
rear frame ( Figure 6 ).
2. Secure the handle at eac h upper mounting hole
with a flang e bolt (3/8 x 1 inc h) and flang e n ut
( Figure 6 ).
3. Select the lo w position for the lo w er mounting
hole ( Figure 6 ).
4. Secure the handle at eac h lo w er mounting hole
with a flang e bolt (3/8 x 1 inc h) and flang e n ut
( Figure 6 ).
Note: T he handle position can be adjusted to
matc h the operator’ s height preference .
13
