Figure 11
1. Control rod 4. Upper control bar
2. Fixed control bar
5. 1 to 1-1/4 inch (25-32mm)
gap
3. Parking brake lever
6. Fitting
7. Chec k the parking brak e adjustment. R efer to
Chec king the Brak es in the Brak e Maintenance ,
pag e 37 .
Step
5
Installing the Hairpin Cotter
Pins and Spacers
Parts needed for this step:
2
Hairpin cotter pin
6 Spacers
Procedure
Un used height-of-cut spacers ma y be stored on
posts and retained b y a hair pin cotter .
Note: Mak e sure there is at least one spacer used
on eac h height-of-cut post.
1. R emo v e the existing rear hair pin cotter pins
from the rear height-of-cut posts ( Figure 12 ).
2. Install a spacer onto both rear height-of-cut
posts and install the hair pin cotter pins
( Figure 12 ).
Figure 12
1. Hairpin cotter
3. Height-of-cut post (rear
shown)
2. Spacer
3. Install a spacer onto both front height-of-cut
posts and install the hair pin cotter pins .
4. On the opposite side of the m uffler ,
install un used spacers onto front and rear
height-of-cut pins and inser t the hair pin cotter
pins ( Figure 13 ).
Figure 13
1. Hairpin cotter
3. Height-of-cut post (front
shown)
2. Unused spacers
16
