Groundsmaster 4500 --D/4700--DHydraulic S ystem Page 4 -- 120
Steering Cylinder Service
1. Tube assembly
2. Lock nut
3. Seal
4. O--ring
5. O--ring
6. Piston
7. O--ring
8. Back--up seal
9. Seal
10. Head
11. Wiper
12. Retaining ring
13. Rod assembly
Figure 102
7
10
4
11
8
5
1
6
3
9
2
12
13
7
10
4
11
8
5
1
6
3
9
2
12
13
30 to 36 ft--lb
(41to48N--m)
