Toro 30881 Service Manual

Groundsmaster 4500 --D/4700--DPage 3 -- 16Yanmar Diesel Engine
Engine
Figure 14
1. LH front engine mount bracket
2. RH front engine mount bracket
3. LH rear engine mount bracket
4. RH rear engine mount bracket
5. Lock washer (16 used)
6. Cap screw (16 used)
7. Engine mount (4 used)
8. Flange head screw (8 used)
9. Flange nut (13 used)
10. Rebound washer (4 used)
11. Lock washer
12. Cap screw (3 used)
13. Cap screw
14. Cap screw
15. Tailpipe support bracket
16. Clamp
17. Engine
18. Negative battery cable
19. Tailpipe
20. Flange nut (4 used)
21. Exhaust flange
22. Exhaust gasket
FRONT
RIGHT
9
1
2
3
4
5
6
7
8
10
11
13
9
12
12
12
8
8
8
7
7
7
9
10
9
9
9
10
10
15
14
16
5
6
5
6
MODEL 30881/30882 SHOWN
18
16
19
20
21
22
17
